AKD Benutzerhandbuch | 25.31.6 PLS.T1 TO PLS.T8

25.31.6 PLS.T1 TO PLS.T8

General Information
Type
Description Sets programmable limit switch time
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
EtherCAT COE and CANopen
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus
Description
These parameters define the time of the PLS pulse for time-based PLS handling.
For further information about the PLS functionality, especially the meaning of the PLS.T1 to PLS.T8
parameter, refer to the PLS.UNITS parameter.
867 KOLLMORGEN | Mai 2013
R/W parameter
ms
0 to 65,536 ms
500 ms
Integer
PLS.EN, PLS.RESET, PLS.STATE, PLS.UNITS, PLS.MODE, PLS.WIDTH1
TO PLS.WIDTH8, PLS.P1 TO PLS.P8
M_01-02-03-000
Variant
Fieldbus
658 PLS.T1
660 PLS.T2
662 PLS.T3
664 PLS.T4
No
666 PLS.T5
668 PLS.T6
670 PLS.T7
672 PLS.T8
Supported
√
√
√
Index/Subindex
34A2h/1 PLS.T1
34A2h/2 PLS.T2
34A2h/3 PLS.T3
34A2h/4 PLS.T4
34A2h/5 PLS.T5
34A2h/6 PLS.T6
34A2h/7 PLS.T7
34A2h/8 PLS.T8
16 bit No M_01-03-00-000
Object Start Version
M_01-02-03-000
