AKD Benutzerhandbuch | 25.30.3 PL.ERRFTHRESH

25.30.3 PL.ERRFTHRESH

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Data Type
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
840 KOLLMORGEN | Mai 2013
NV Parameter
Sets the maximum position error.
Depends on or
Rotary: counts, rad, deg, (custom units), 16-bit counts
Linear: counts, mm, µm, (custom units), 16-bit counts
Rotary:
0.000 to 5,123,372,000,000,005.000 counts
0.000 to 7,495,067.136 rad
0.000 to 429,436,076.032 deg
0.000 to 5,964,389.888 (custom units)
0.000 to 78,176,452,636.718 16-bit counts
Linear:
0.000 to 5,123,372,000,000,005.000 counts
0.000 to 1,192,877.952*MOTOR.PITCH (s: 790) mm
0.000 to 1,192,878,014.464*MOTOR.PITCH (s: 790)
µm
0.000 to 5,964,389.888 (custom units)
0.000 to 78,176,452,636.718 16-bit counts
Rotary:
42,949,672,960.000 counts
62.832 rad
3,600.000 deg
50.000 (custom units)
655,360.000 16-bit counts
Linear:
42,949,672,960.000 counts
10.000*MOTOR.PITCHMOTOR.PITCH (s: 790)mm
10,000.000*MOTOR.PITCH µm
50.000 (custom units)
655,360.000 16-bit counts
Float
PL.ERR
AKD BASIC Information
Integer
Variant Supported
√
√
√
