AKD Benutzerhandbuch | 25.16.11 FB1.MECHPOS

25.16.11 FB1.MECHPOS

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 288
Description
FB1.MECHPOS reads the mechanical angle which is equal to the lower 32 bits in the 64-bit position feed-
back word.
Related Topics
Rückführung 1 (s: 69)
610 KOLLMORGEN | Mai 2013
R/O Parameter
Reads the mechanical posi-
tion.
counts
0 to 4,294,967,295 counts
N/A
Integer
N/A
Variant Supported
No 32 bit
√
√
√
No M_01-03-00-000
