AKD Benutzerhandbuch | 25.31.5 PLS.STATE

25.31.5 PLS.STATE

General Information
Type
Description Reads the programmable limit switch state.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 656
Description
This parameter is a bit variable and displays the current status of the individual programmable limit
switches.
Example
Bit 0 = 0: Programmable Limit Switch 1 (PLS 1) is not active.
Bit 0 = 1: Programmable Limit Switch 1 (PLS 1) is active.
Bit 7 = 0: Programmable Limit Switch 8 (PLS 8) is not active.
Bit 7 = 1: Programmable Limit Switch 8 (PLS 8) is not active.
Related Topics
Programmierbarer Endschalter (s: 123)
R/O Parameter
N/A
N/A
N/A
Integer
PLS.EN, PLS.RESET, PLS.UNITS, PLS.MODE, PLS.P1 TO PLS.P8,
PLS.WIDTH1 TO PLS.WIDTH8, PLS.T1 TO PLS.T8
M_01-02-03-000
Variant Supported
Index/Subindex Object Start Version
34A3h/4
No 16 bit
√
√
√
M_01-02-03-000
No M_01-03-00-000
KOLLMORGEN | Mai 2013 866
