AKD Benutzerhandbuch | 25.10.6 DIN1.INV to DIN7.INV

25.10.6 DIN1.INV to DIN7.INV

General Information
Type
Description Sets the indicated polarity of a digital input mode.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus
Description
Sets the indicated polarity of a digital input mode.
Example
DIN1.INV = 0 : Input is active high.
DIN1.INV = 1 : Input is active low.
Related Topics
Digitale Eingänge und Ausgänge (s: 101)
RW Parameter
N/A
0 to 1
0
Boolean
N/A
M_01-00-00-000
Variant
120 DIN1.INV
130 DIN2.INV
140 DIN3.INV
150 DIN4.INV No
160 DIN5.INV
170 DIN6.INV
180 DIN7.INV
Supported
√
√
√
8 bit No M_01-03-00-000
KOLLMORGEN | Mai 2013 483
