AKD Benutzerhandbuch | 25.12.9 DOUT9.STATEU to DOUT11.STATEU

25.12.9 DOUT9.STATEU to DOUT11.STATEU

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-05-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
Modbus
Description
This parameter allows the user to set the level of the output signal, when the IO is set to output mode.
Parameter value is 0 if signal is low and 1 if signal is high. DIOx.INV can affect the signals driven onto the
X9 connector.
This parameter can be written at any time. The value is only guaranteed to correspond to the output on the
X9 connector when DRV.EMUEMODE is set to 10 and the DIOX.DIR is 0.
Example
The following settings set the direction for the differential signals on pin 4 and 5, so that the output will
have a high level signal.
First set the following settings:
DRV.EMUEMODE 10
DIO10.DIR 1
DOUT10.STATEU 1
Then change the level of the signal:
DOUT.STATEU 0
or
DIO10.INV
Note: Inverting the signal will also alter the signal in input mode.
Related Topics
508 KOLLMORGEN | Mai 2013
NV Parameter
Allows user to set level of selected pin to high or
low.
N/A
0 to 1
0
U8
N/A
Variant
Index/Subindex
1566 DOUT9.STATEU
1458 DOUT10.STATEU
1462 DOUT11.STATEU
Supported
√
N/A
N/A
Is 64 bit? Attributes Signed? Object Start Version
No 8 bit No M_01-06-03-000
