AKD Benutzerhandbuch | 25.12.8 DOUT9.STATE to DOUT11.STATE

25.12.8 DOUT9.STATE to DOUT11.STATE

General Information
Type
Description
Units
Range
Default Value
Data Type
See Also
Start Version
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
Modbus
Description
This parameter allows the user to see the actual level of the output signal, when the IO is set to output
mode. Parameter value is 0 if signal is low and 1 if signal is high. DIOx.INV can affect the signals driven
onto the X9 connector.
This parameter can be read at any time. The value is only guaranteed to correspond to the output on the
X9 connector when DRV.EMUEMODE is set to 10 and the DIOX.DIR is 0.
Related Topics
DIO9.DIR to DIO11.DIR (s: 496)
DIO9.INV to DIO11.INV (s: 495)
DOUT9.STATEU to DOUT11.STATEU (s: 508)
DRV.EMUEMODE (s: 539)
NV parameter
Shows on selected pin if signal is high or low.
N/A
0 to 1
0
U8
N/A
M_01-05-00-000
Variant
Index/Subindex
1564 DOUT9.STATE
1456 DOUT10.STATE
1460 DOUT11.STATE
Supported
√
√
N/A
Is 64 bit? Attributes Signed? Object Start Version
No 8 bit No M_01-06-03-000
