AKD Benutzerhandbuch | 25.5.2 AOUT.ISCALE

25.5.2 AOUT.ISCALE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-01-01-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 18
Description
AOUT.ISCALE sets the analog current scale factor that scales the analog output (AOUT.VALUE) for
AOUT.MODE = 4 or 5. The value entered is the motor current per 10 V of analog input or output. This
value may be either higher or lower than 100%, but the actual analog I/O will be limited by the application
current limit (IL.LIMITN (s: 735) and IL.LIMITP (s: 736)).
Related Topics
Analogausgang (s: 118)
NV Parameter
Sets the analog current scale fac-
tor.
A/V
0.001 to 22.4 A/V
0.001 to 22.4 A/V
Float
AOUT.VALUE (s: 424)
Variant Supported
No 32 bit
√
√
√
No M_01-03-00-000
