AKD Benutzerhandbuch | 25.42.4 WS.CHECKV

25.42.4 WS.CHECKV

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Ver-
sion
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1702
Description
This parameter sets the velocity threshold which has to be exceeded to activate commutation monitoring.
Related Topics
Wake&Shake Übersicht (s: 71) | WS.CHECKT (s: 990)| UNIT.VROTARY (s: 940) | UNIT.VLINEAR (s:
939)
R/W Parameter
This parameter sets the velocity threshold which has to be exceeded to activate
commutation monitoring.
Depends on UNIT.VROTARY or UNIT.VLINEAR.
Unit
0
1
2
3
N/A
S32
M_01-06-03-000
Yes 64-bit
Rotary
0 to 15,000 rpm
0 to 250 rps
0 to 90,000 deg/s
0 to 1250 PIN/POUT
Yes
Linear
0 to 6,7108,864 counts/s
0 to 8,000 mm/s
0 to 589934 um/s
0 to 1250 PIN/POUT
KOLLMORGEN | Mai 2013 991
