AKD Benutzerhandbuch | 25.2.4 AIN.ISCALE

25.2.4 AIN.ISCALE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-01-01-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 4
Description
AIN.ISCALE sets the analog current scale factor that scales the analog input (AIN.VALUE) for DRV.O-
PMODE (s: 574) = 1 (analog torque mode).
The value entered is the motor current per 10 V of analog input. This value may be either higher or lower
than 100%, but the actual analog input will be limited by the application current limit (IL.LIMITN (s: 735)
and IL.LIMITP (s: 736)).
Related Topics
Analogeingang (s: 117)
Blockschaltbild für den Positions-/Geschwindigkeitsregelkreis (s: 328) (for the drive controller envi-
ronment).
NV Parameter
Sets the analog current scale fac-
tor.
A/V
0.001 to 22.4 A/V
0.001 A/V
Float
AIN Parameters (s: 387)
Variant Supported
No 32 bit
√
√
√
No M_01-03-00-000
KOLLMORGEN | Mai 2013 393
