AKD Benutzerhandbuch | 25.19.7 FBUS.STATE

25.19.7 FBUS.STATE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-08-00-000
Variants Supported
AKD Analog
AKD CANopen via CAN
AKD EtherCAT (CANopen)
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1746
Description
FBUS.STATE returns the current state of the fieldbus. The value returned is dependent upon the fieldbus
being used.
Value
-1
0
1
2
3
4
5
8
127
R/O
Reads the state of the fieldbus.
N/A
Depends on fieldbus. See table
below.
Depends on fieldbus. See table
below.
Integer
Variant
No
CANopen over CAN CANopen over EtherCAT
Not connected Not connected
Init. -
N/A Init.
N/A Pre-operational
- Boot
Stopped Safe-operational
Operational -
- Operational
Pre-operational -
Supported
N/A
√
√
N/A
N/A
N/A
8-bit Yes
