Customer menu
Parameter Setting
Language DE
Minimum operating 1.8 bar
pressure "P "
0
Next maintenance 12 months
Volt-free contact All
Make-up
Maximum make-up 0 Litres
quantity
Maximum make-up time 20 minutes
Maximum make-up cycles 3 cycles within 2
hours
Degassing
Degassing programme Continuous
degassing
Continuous degassing 12 hours
time
Softening (Only if "With
softening Yes")
Shut off make-up No
Hardness reduction 8°dH
Maximum make-up 0 Litres
quantity
Soft water capacity 0 Litres
Cartridge replacement 18 months
10.3.4 Setting degassing programmes
1. Press "Settings".
–
The controller switches to the setting area.
2. Press "Customer >".
–
The controller opens the Customer menu.
3. Press "Degassing >".
–
The controller switches to the selected area.
–
Use the scroll bar to navigate "up" and "down" through the list.
Comment
Display language.
 8.2 "Variomat switching
points",  45.
Time left to the next due
maintenance.
Only if make-up has been
selected in the customer menu
with "With water meter Yes".
Default setting
In the case of soft water residual
capacity = 0
= Target – Actual
Replace cartridge.
Variomat Touch — 22.07.2024
4. Press "(012) Degassing programme".
–
The controller opens the list of degassing programmes.
5. To select a menu item, press the "Up" or "Down" scroll bar until this menu
item is displayed.
•
Press the desired button.
–
"Continuous degassing" is selected in this example.
–
Interval degassing is deactivated.
–
Make-up degassing is deactivated.
•
Confirm your selection with "OK".
Continuous degassing is activated.
6. Press "(013) Time, continuous degassing".
7. Set the time for continuous degassing.
•
Use the "Left" and "Right" buttons to select the display value.
•
Use the "Up" and "Down" buttons to change the display value.
•
Confirm your entries with "OK".
The time for continuous degassing is set.
–
Press "i" to display a help text for the selected area.
–
Press "X" to cancel your input without saving the new settings. The controller
automatically opens again the list.
10.3.5 Degassing programmes – overview
No degassing
This programme is selected when the temperatures of the media to be degassed
exceed the permissible Variomat temperature of 70° C (158° F) or the Variomat is
combined with a Servitec vacuum degassing system.
Continuous degassing
This programme is selected after commissioning and repairs of the connected
system. The device will continuously degas for a set period of time. Air bubbles
within the system are quickly removed.
Start/setting:
•
Automatic start after execution of the start routine during commissioning.
•
Activated from the Customer menu.
•
The degassing time can be set in the Customer menu, dependent on the
actual system.
Controller
