I/O module (optional expansion module)
5.2.2 Setting the module address
Setting of the module address on the I/O module's main circuit board
1 DIP switch
DIP-switch position
DIP switch 1 – 4: •
•
•
DIP switch 5:
5.2.3 I/O module default settings
The inputs and outputs of the I/O module each have default settings.
These default settings can be changed, if required, and adjusted to local conditions.
Responses by the inputs 1 – 6 of the I/O module are recorded and displayed in the device controller's fault memory.

Note!
•
Default settings apply to software version V1.10 and higher.
•
All digital inputs and outputs can be set freely as option. The setting is carried out by Reflex Customer Service,  13.1 "Reflex Customer
Service",  56
Location Signal Message text
evaluation
INPUTS
1 Normally closed External temperature
contact
2 Normally closed External signal, Minimum
contact
3 Normally closed
contact
4 Normally open
contact
5 Normally open
contact
6 Normally open
contact
OUTPUTS
1 Changeover
contact
2 Changeover
contact
3 Changeover
contact
4 Changeover
contact
5 Changeover
contact
36 — English
For setting the module address
Variable setting to ON or OFF
Permanently to position ON
Error
memory
entry
Yes
monitoring
Yes
pressure
Manual make-up Yes
Emergency-Off Yes
Manual pump 1 Yes
Manual OF-1 Yes
--- ---
--- ---
--- ---
--- ---
--- ---
