Controller
A three-digit PM code is assigned to the setting options
PM Description
Code
001 Select the language
002 Set the time
003 Set the date
Execute null balancing
–
The primary vessel must be empty
–
The system checks whether the signal from the level sensor
matches the selected primary vessel.
005 Set the minimum operating pressure P
points",  45.
Degassing >
•
010 Degassing programme
–
No degassing
–
Continuous degassing
–
Interval degassing
–
Run-on degassing
•
011 Continuous degassing time
Make-up >
• Maximum make-up time ...min
023
• Maximum make-up cycles ... /2 h
024
•
027 With water meter "Yes/'No"
–
If "Yes", continue with 028
–
If "No", continue with 007
•
028 Make-up quantity (Reset) "Yes/No"
–
If "Yes", reset to "0"
•
029 Maximum make-up quantity ... l
•
030 Softening "Yes/'No"
–
If "Yes", continue with 031
–
If "No", continue with 007
Maintenance interval... months
007
008 Floating contact
•
Message selection >
– Message selection: only messages marked with "√" are
output.
–
All messages: All messages are output.
Change remote data "Yes/No"
015
Fault memory > History of all messages
Parameter memory > History of parameter input
Display settings > Brightness, screen saver
• Brightness ... %
009
• Screen saver brightness ... %
010
• Screen saver delay ...min
011
•
018 Secure access "Yes/No"
Information >
•
Vessel
•
Volume
•
Weight
•
Diameter
•
Position
–
Position in %
•
Software version
50 — English
,  8.2 "Variomat switching
0
Variomat Touch — 22.07.2024
10.3.1.2 Setting the customer menu - "Time" example
The setting of system-specific values is explained below using the setting of the
time as example.
To adjust the system-specific values, proceed as follows:
1. Press "Settings".
–
The controller switches to the setting area.
2. Press "Customer >".
–
The controller opens the Customer menu.
3. Press the required area.
–
The controller switches to the selected area.
–
Use the scroll bar to navigate through the list.
4. Set the system-specific values for the individual areas.
•
Use the "Left" and "Right" buttons to select the display value.
•
Use the "Up" and "Down" buttons to change the display value.
•
Confirm your entries with "OK".
–
Press "i" to display a help text for the selected area.
–
Press "X" to cancel your input without saving the new settings. The controller
automatically opens again the list.
10.3.2 Service menu
This menu is protected with a password. It can be accessed only by the Reflex
Customer Service.
10.3.3 Default settings
The device controller is shipped with the following default settings. Use the
Customer menu to adjust these values to local conditions. In specific cases, it is
possible to further adjust the values in the Service menu.
