146/549
Kommunikation, Führungskommunikation
Bosch Rexroth AG R911410072 _Ausgabe 03
1
ctrlX CORE HMI/Engineering-Port
2
IP-fähige Industrial-Ethernet Führungskommunikation (Feld‐
bus)
3
Virtuelle Ethernet Schnittstelle über USB zum Panel
4
Panel, das flexibel während des Betriebs von Gerät zu Gerät
steckbar ist
5
Engineering
Abb. 7-16:
Kommunikationsschnittstellen
Als bevorzugte Topologie sollte die Ring-Topologie gewählt wer‐
den.
2
IP-fähige Industrial-Ethernet Führungskommunikation (Feld‐
bus)
Abb. 7-17:
Ring-Topologie
Es
besteht
die
Möglichkeit,
MultiEthernet-Interface (ET) oder dem Optionsmodul "Sercos" als Sercos-
ctrlX DRIVE Runtime AXS-V-03 Funktionen
ctrlX
DRIVE-Regelgeräte
mit
einem
