Controller
10.4
Messages
The messages are impermissible deviations from the normal state. They can be
output either via the RS-485 interface or via two floating message contacts.
The controller displays the messages with a help text.
Message causes can be eliminated by the operator or a specialist workshop. If
this is not possible, contact the Reflex Customer Service.
Note!
When the cause for the message is eliminated, you must acknowledge
the fault with "OK" at the controller's operator panel.
ER
Alarm
Floating
Code
contact
01
Minimum pressure
YES
02.1 Insufficient water
-
03
High water
YES
04.1 Pump
YES
05
Pump run time
-
06
Make-up time
-
07
Make-up cycles
-
08
Pressure measurement YES
09
Level sensor
YES
10
Maximum pressure
-
11
Make-up quantity
-
15
Make-up valve
-
16
Power failure
-
19
-
Stop ˃ 4 hours
20
Max. Make-up volume
-
46 — English
Causes
•
Set value not reached.
•
Water loss in the system.
•
Pump fault.
•
Controller in Manual mode
•
Set value not reached.
•
Make-up disabled.
•
Air in the system.
•
Dirt trap clogged.
•
Set value exceeded.
•
Make-up disabled.
•
Water intake through a leak in a thermal transfer
medium of the user.
•
"VG" and "VF" tanks too small.
Pump disabled.
•
Pump jammed.
•
Pump motor defective.
•
Pump motor contactor tripped.
•
Fuse defective.
•
Set value exceeded.
•
Severe water loss in the system.
•
Cap valve at the intake side closed.
•
Air in the pump.
•
Solenoid valve in the overflow line does not close.
•
Set value exceeded.
•
Water loss in the system.
•
Make-up line not connected.
•
Make-up rate insufficient.
•
Make-up hysteresis too low.
Set value exceeded.
Controller receives incorrect signal.
Controller receives incorrect signal.
•
Set value exceeded.
•
Pressure relief pipe not functioning.
•
Dirt trap clogged.
"With water meter" must be activated in the Customer menu.
•
Set value exceeded.
•
Severe water loss in the system.
Contact water meter measures without make-up request.
No power.
Device is in Stop mode for more than 4 hours.
Set value exceeded.
Variomat 140 — 25.09.2020 - Rev. A
Note!
Floating contacts, setting in the Customer menu, 8.6 "Parametrising
the controller in the Customer menu", 42.
To reset a fault message, proceed as follows:
1.
Touch the display.
–
The current fault messages are displayed.
2.
Touch a fault message.
–
The system displays the possible causes for the fault.
3.
When the fault is eliminated, confirm the fault with "OK".
•
Check set value in the Customer or Service
menu.
•
Check water level.
•
Check pump.
•
Set the controller to Automatic mode.
•
Check set value in the Customer or Service
menu.
•
Clean the dirt trap.
•
Check functioning of the "PV1" solenoid valve.
•
If necessary, manually add water.
•
Check set value in the Customer or Service
menu.
•
Check functioning of the "WV1" solenoid
valve.
•
Drain water from the "VG" tank.
•
Check site heat transfer medium for leaks.
•
Rotate the pump with screwdriver.
•
Replace the pump motor.
•
Electrically test the pump motor.
•
Replace the fuse.
•
Check set value in the Customer or Service
menu.
•
Check the water loss and correct, if necessary.
•
Open the cap valve.
•
Vent the pump.
•
Check functioning of the "PV1" solenoid valve.
•
Check set value in the Customer or Service
menu.
•
Check water level.
•
Connect make-up pipe
•
Check set value in the Customer or Service
menu.
•
Seal any leak in the system.
•
Connect the plug.
•
Check functioning of the pressure sensor.
•
Check the cable for damage.
•
Check the pressure sensor.
•
Check functioning of the load cell.
•
Check the cable for damage.
•
Connect the plug.
•
Check set value in the Customer or Service
menu.
•
Check functioning of the pressure relief pipe.
•
Clean the dirt trap.
•
Check set value in the Customer or Service
menu.
•
Check water loss in the system and repair, if
necessary.
Check the make-up valve for leaks.
Connect to power supply.
Set the controller to Automatic mode.
Reset the "Make-up quantity" meter in the Customer
menu.
Remedy
Alarm
reset
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
-
-
-
-
-
