AKD Benutzerhandbuch | 25.13.7 DOUT1.STATEU AND DOUT2.STATEU

25.13.7 DOUT1.STATEU AND DOUT2.STATEU

General Information
Type
Description
Units
Range
Default Value 0
Data Type
Start Version M_01-01-01-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter
DOUT1.STATEU Profinet
DOUT2.STATEU Profinet
Fieldbus Index/Subindex
Modbus 204
214
Description
Set the state of the digital output node as follows:
0 = deactivated
1 = activated
DOUT1.STATEU and DOUT2.STATEU are used when DOUTx.MODE = 0 (user mode).
596 KOLLMORGEN | Dezember 2014
R/W Parameter
Sets the state of the digital output
node.
N/A
0 to 1
Integer
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Fieldbus Address Attributes Signed?
2102
sercos ® III
2107
sercos ® III
Is 64 bit? Attributes Signed? Object Start Version
DOUT1.STATEU No
DOUT2.STATEU
Byte No
2 Octets
Byte
2 Octets
8 bit No
M_01-03-00-000
