AKD Benutzerhandbuch | 25.19.9 FB3.POFFSET

25.19.9 FB3.POFFSET

General Information
Type
Description
Units
Range
Default Value 0
Data Type
See Also
Start Version M_01-05-11-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1654
Description
FB3.POFFSET is the value added to the primary feedback position (FB3.P (➜ S. 810)).
Example
If FB3.P is 10000 counts and FB3.POFFSET is set to –10000 counts, then the next read of FB3.P will
return ~0 counts.
814 KOLLMORGEN | Dezember 2014
NV-Parameter
Sets the offset for tertiary feedback.
counts, custom units
-5,123,372,000,000,005.000 to 5,123,372,000,000,005.000 counts
or
-10,485,760.000 to 10,485,760.000 custom units
S64
N/A
Supported
Address Attributes Signed?
2827
DWord Yes
8 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
M_01-06-03-000
64-bits Yes
