AKD Benutzerhandbuch | 25.17.10 FB1.IDENTIFIED

25.17.10 FB1.IDENTIFIED

General Information
Type
Description
Units
Range
Default Value N/A
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus Address Attributes Signed?
Profinet 2142
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 284
Description
This parameter is set according to FB1.SELECT on drive power up if FB1.SELECT is not –1; other-
wise the parameter value is read from the drive memory.
Type Description
0
Unknown
1 No encoder
10 Incremental encoder with A/B Quad, marker pulse and Hall
R/O Parameter
Reads the type of feedback device used by the drive/motor.
N/A
N/A
Integer
FB1.SELECT
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Byte No
2 Octets
No 8 bit
No
M_01-03-00-000
No
KOLLMORGEN | Dezember 2014 749
