AKD Benutzerhandbuch | 25.19.6 FB3.P
This parameter is only supported on drives with model numbers similar to AKD-x-xyyzz-NBxx-yyzz
and will only work with Endat 2.2 multiturn encoder. The output format is 32:32 the upper 32 bits repres-
ents the multiturns and the lower 32 bits for position of the feedback.
Related Topics
DRV.EMUEMODE (➜ S. 649) | FB3.PUNIT (➜ S. 816) | FB3.PIN | FB3.POUT | FB3.PDIR (➜ S.
812) |
