AKD Benutzerhandbuch | 25.25.11 IL.FOLDFTHRESH

25.25.11 IL.FOLDFTHRESH

General Information
Type
Description
Units
Range
Default Value Drive peak current
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CANopen 3420h/0
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 436
Description
IL.FOLDFTHRESH is the fault level of the current foldback algorithm. If IL.IFOLD (➜ S. 920) drops
below the value for IL.FOLDFTHRESH, then a fault is generated and the drive is disabled.
To avoid reaching the current foldback fault level, set IL.FOLDFTHRESHU well below the continuous
current value for both the drive and the motor or set the IL.FOLDFTHRESHU value to zero.
912 KOLLMORGEN | Dezember 2014
R/O Parameter
Reads the foldback fault level.
Arms
0 to 500 Arms
(DRV.IPEAK)
Float
Foldback
Supported
Index/Subindex Object Start Version
Address Attributes Signed?
2218
DWord No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit No M_01-03-00-000
