AKD Benutzerhandbuch | 25.8.3 CMPx.MODBOUND1
Variant
AKD-N
AKD-C
Description
Use this keyword to set the first modulo bound. CMPx.MODBOUND1 and CMPx.MODBOUND2 (➜
S. 522) must both be set before the modulo functionality can be activated. There is no requirement that
the second modulus bound be larger than the first modulus bound.
CMPx.MODBOUND1 must be set before CMPx.SETPOINT (➜ S. 532).
Example
The following example sets the first modulo bound to one billion counts for CMP1.
-->CMP1.MODBOUND1 1000000000
Related Topics
Komparatoren (Vergleicher) (➜ S. 129)
CMPx.MODBOUND2 (➜ S. 522) | CMPx.MODEN (➜ S. 526) | CMPx.ARM (➜ S. 518)
Supported
No
No
