AKD Benutzerhandbuch | 25.29.32 MOTOR.TEMPC

25.29.32 MOTOR.TEMPC

General Information
Type
Description
Units
Range
Default Value N/A
Data Type
Start Version M_01-10-04-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
When the motor has a thermistor with linear characteristics (MOTOR.RTYPE = 2, 3 or 4),
MOTOR.TEMPC returns the motor temperature in degrees Celsius, which is calculated from the resi-
stance of the motor thermistor.
There is no algorithm to convert from resistance to degrees Celsius for non-linear thermistors. In this
case, MOTOR.TEMPC returns -32,768 which is an invalid temperature.
Related Topics
9.1 Motor | MOTOR.TEMP (➜ S. 1034) | MOTOR.RTYPE (➜ S. 1024)
1036 KOLLMORGEN | Dezember 2014
R/O Parameter
Reads the motor temperature in degrees Cel-
sius.
Degrees Celsius
-2 15 to 2 15
Integer
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
