AKD Benutzerhandbuch | 25.29.16 MOTOR.LDLL

25.29.16 MOTOR.LDLL

General Information
Type
Description
Units
Range
Default Value 17.000
Data Type
Start Version M_01-11-00-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Descriptio
This parameter is the motor line to line direct axis inductance. It is supported for the IPM motor type
(MOTOR.TYPE = 6).
Related Topics
9.1 Motor | MOTOR.LQLL (➜ S. 1012) | IL.KPDRATIO (➜ S. 928)
1010 KOLLMORGEN | Dezember 2014
NV Parameter
Motor line to line direct axis induc-
tance.
mH
1 to 2^31
Float
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
This parameter is automatically configured for Kollmorgen motors when
MOTOR.AUTOSET = 1.
No
