AKD Benutzerhandbuch | 25.7.12 CAP0.T, CAP1.T

25.7.12 CAP0.T, CAP1.T

General Information
Type
Description
Units
Range
Default Value N/A
Data Type
Start Version M_01-00-00-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter Fieldbus
Profinet
CAP0.T
sercos ® III
Profinet
CAP1.T
sercos ® III
Fieldbus
EtherCAT COE and CANopen
R/O Parameter
Reads time capture (if time capture was con-
figured).
ns
N/A
U32
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Address Attributes Signed?
2038 DWord
4 Octets
2051 DWord
4 Octets
Index/Subindex
20A0h/0 CAP0.T
20A0h/0 CAP0.T
20A2h/0 CAP1.T
20A3h/0 CAP1.T
No
No
Object Start Version
M_01-00-00-000
