Inverter-Parameter (Adresse / Auflösung / Typ)
st: status info
Sub-
Index CAN Type IDtxt
Idx
2100h 0 V UINT16 st00
2101h 0 V UINT16 st01
2102h 0 V INT8 st02
2103h 0 V INT32 st03
2104h 0 V UINT16 st04
210Ch 0 V UINT16 st12
210Dh 0 V UINT16 st13
210Eh 0 V UINT16 st14
210Fh 0 V UINT16 st15
2120h 0 V INT32 st32
2121h 0 V INT32 st33
2122h 0 V INT16 st34
2123h 0 V UINT32 st35
2124h 0 V INT32 st36
2125h 0 V INT32 st37
2130h 0 V INT16 st48
© 2021 KEB Automation KG
Name Upper Limit
(CiA 0x6041) statusword ---
(CiA 0x603F) error code ---
(CiA 0x6061) modes of opera-
---
tion display
(CiA 0x6043) vl velocity demand ---
brake ctrl status ---
state machine display ---
state and error display ---
active controlword ---
combined controlword ---
(CiA 0x606C) velocity actual
---
value
(CiA 0x6064) position actual
---
value
(CiA 0x6077) torque actual va-
---
lue
system counter ---
(CiA 0x60F4) following error ac-
---
tual value
(CiA 0x6062) position demand
---
value
rho actual value ---
Lower Limit Default Value Mult. Div
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
--- --- 1 1
Unit PD RO EOAD
✓
--- X X
✓
--- X X
✓
--- X X
✓
1/min X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
✓
--- X X
