AKD Benutzerhandbuch | 25.34.9 REC.RETRIEVEDATA
If REC.STOPTYPE==1, then this parameter returns the next section of data in the buf-
l
fer (even if it reached the end of the buffer, it will return to the beginning of the buffer and
add the data from index 0.)
If REC.STOPTYPE==1 and the retrieve is too slow (gets overrun by the recorder), an
l
overflow error message is returned instead of the retrieved data.
If REC.STOPTYPE==0 and no index is received, continuously send the sections of
l
data until the end of the buffer is reached. Then, return to the beginning of buffer and con-
tinue.
A new REC.TRIG (➜ S. 1167) command automatically sets the index to 0.
l
Example
The following example retrieves data from index 100 in the size of 10 (hence places 100 to 109 in the
buffer)
REC.NUMPOINTS 1000
REC.RETRIVESIZE 10
REC.TRIG
REC.RETRIEVEDATA 100
Related Topics
Oszilloskop (➜ S. 248)
