AKD Benutzerhandbuch | 25.34.19 REC.TRIGTYPE

25.34.19 REC.TRIGTYPE

General Information
Type R/W Parameter
Description Sets the trigger type.
Units 0 = immediate
1 = command
2 = parameter
3 = boolean
Range 0 to 2
Default 0
Value
Data Type Integer
See Also REC.TRIG (➜ S. 1167), REC.TRIGPARAM, REC.TRIGVAL, REC.TRIGSLOPE
REC.TRIGPOS
Start Ver- M_01-00-00-000
sion
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus Address Attributes Signed?
Profinet 2364
sercos ® III
Description
REC.TRIGTYPE sets the type of trigger.
Input values are as follows:
Value Description
0 Recording starts immediately
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Byte No
2 Octets
