AKD Benutzerhandbuch | 25.47.11 VL.FBFILTER

25.47.11 VL.FBFILTER

General Information
Type
Description
Units
Range
Default Value N/A
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
Variant
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CANopen 3407h/1
Fieldbus
Parameter
Profinet VL.FBFILTER_32 2429
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes
Modbus 858
Description
This parameter returns the same value as VL.FB (➜ S. 1287), filtered through a 10 Hz filter.
Related Topics
R/O Parameter
Filters VL.FB (➜ S. 1287) value; active in opmodes 1 (velocity) and 2 (position)
only.
Depends on UNIT.VROTARY (➜ S. 1251) or UNIT.VLINEAR (➜ S. 1249)
Rotary: rpm, rps, deg/s, (custom units)/s, rad/s
Linear: counts/s, mm/s, µm/s, (custom units)/s
N/A
Float
VL.FB (➜ S. 1287)
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Index/Subindex Object Start Version
Address Attributes Signed?
Yes low 32 bit word Yes
No
M_01-00-00-000
DWord Yes
8 Octets
Signed? Object Start Version
M_01-03-00-000
KOLLMORGEN | Dezember 2014 1289
