Montaj
4.2.2 Racorduri variabile de proces HygienicMaster
Diametru nominal DN
mm
1 ... 2
3 ... 10
15
20
25
32
40
50
65
80
100
18 - RO
inch
1/25 ... 3/32"
3/8"
1/2"
3/4"
1
1 1/4"
1 1/2"
2
2 1/2"
3
4
FEX300, FEX500
Cuplul maxim de strângere
Nm
PVC/POM: 0,2 Messing/1.4571: 3
8
10
21
31
60
80
5
5
15
14
