Notes on the operating manual
1
Notes on the operating manual
This operating manual is an important aid for ensuring the safe and reliable
functioning of the device.
Reflex Winkelmann GmbH accepts no liability for any damage resulting from
failure to observe the information in this operating manual. In addition to the
requirements set out in this operating manual, national statutory regulations and
provisions in the country of installation must also be complied with (concerning
accident prevention, environment protection, safe and professional work practices,
etc.).
This operating manual describes the device with basic equipment and interfaces
for optional equipment with additional functions.
Notice!
Every person installing this equipment or performing any other work at the
equipment is required to carefully read this operating manual prior to
commencing work and to comply with its instructions. The manual is to be
provided to the product operator and must be stored near the product for
access at any time.
2
Liability and guarantee
The device has been built according to the state of the art and recognised safety
rules. Nevertheless, its use can pose a risk to life and limb of personnel or third
persons as well as cause damage to the system or other property.
It is not permitted to make any modifications at the device, such as to the hydraulic
system or the circuitry.
The manufacturer shall not be liable nor shall any warranty be honoured if the
cause of any claim results from one or more of the following causes:
•
Improper use of the device.
•
Unprofessional commissioning, operation, service, maintenance, repair or
installation of the device.
•
Failure to observe the safety information in this operating manual.
•
Operation of the device with defective or improperly installed
safety/protective equipment.
•
Failure to perform maintenance and inspection work according to schedule.
•
Use of unapproved spare parts or accessories.
Prerequisite for any warranty claims is the professional installation and
commissioning of the device.
Note!
Arrange for Reflex Customer Service to carry out commissioning and
annual maintenance, 12.1 "Reflex Customer Service", 37.
3
Safety
3.1
Explanation of symbols
3.1.1
Symbols and notes used
The following symbols and signal words are used in this operating manual.
DANGER
Danger of death and/or serious damage to health
•
The sign, in combination with the signal word 'Danger', indicates
imminent danger; failure to observe the safety information will result in
death or severe (irreversible) injuries.
WARNING
Serious damage to health
•
The sign, in combination with the signal word 'Warning', indicates
imminent danger; failure to observe the safety information can result in
death or severe (irreversible) injuries.
CAUTION
Damage to health
•
The sign, in combination with the signal word 'Caution', indicates danger;
failure to observe the safety information can result in minor (reversible)
injuries.
22 — English
ATTENTION
Damage to property
•
The sign, in combination with the signal word 'Attention', indicates a
situation where damage to the product itself or objects within its vicinity
can occur.
Note!
This symbol, in combination with the signal word 'Note', indicates useful
tips and recommendations for efficient handling of the product.
3.2
Personnel requirements
Assembly, commissioning and maintenance as well as connection of the electrical
components may only be carried out by knowledgeable and appropriately qualified
electricians.
3.3
Personal protective equipment
Use the prescribed personal protective equipment as required (e.g. ear protection,
eye protection, safety shoes, helmet, protective clothing, protective gloves) when
working on the system.
Information on personal protective equipment requirements is set out in the
relevant national regulations of the respective country of operation.
3.4
Intended use
The device is a pressure maintaining station for heating and cooling water
systems. It is used to maintain the water pressure and to add water within a
system. The devices may be used only in systems that are sealed against
corrosion and with the following water types:
•
Non-corrosive
•
Chemically non-aggressive
•
Non-toxic
The ingress of atmospheric oxygen by permeation into the entire heating and
cooling water system, make-up water and similar must be reliably minimized
during operation.
3.5
Inadmissible operating conditions
The device is not suitable for the following applications:
•
Mobile system operation.
•
Outdoor operation.
•
For use with mineral oils.
•
For use with flammable media.
•
For use with distilled water.
Note!
It is not permitted to make any modifications to the hydraulic system or
the circuitry.
3.6
Residual risks
This device has been manufactured to the current state of the art. However, some
residual risk cannot be excluded.
Note!
When installing the site safety valve, the operator must ensure that there
is no danger during blow-off.
Note!
Equipment parts with a safety function in respect of water-side pressure
limiting according to the Pressure Equipment Directive 2014/68/EU and
temperature limiting according to the Pressure Equipment Directive
2014/68/EU are not supplied. The operator is responsible for site
provision of water-side pressure and temperature protection.
