ECOLAB EcoAdd Betriebsanleitung Seite 315

[Set Batch] - [Initial batch]
4
7
Fig. 60: Batch - [Initial batch]
1.
[Call the main menu]:
2.
[Select Configuration]:
3.
Use the scrollbar to go to the [Batch ] menu item.
4.
[Select Batch].
ð Screen switches to the [Batch]
5.
'Select Initial batch' .
ð The 'Initial preparation' option field is marked.
6.
[ Press the Next button]
ð The screen changes to the setting: 'Initial batch' / 'Quantity' .
7.
Use the slider to enter the quantity in litres (before the decimal point).
8.
'Select the quantity details after the decimal point' .
9.
Use the slider to enter the quantity in litres (after the decimal point).
10. Press the Next button
ð The screen changes to the setting: 'Initial batch' / 'Capacity' .
11. Use the slider to enter the capacity in percent (%).
12. Press the
button.
ð The setting is saved, and the screen switches back to the batch overview.
13. Press the
button to return to the [Configuration] menu.
14. Press the
button to return to the [Main menu].
15. Press the
button to return to the [Operating display].
5
3
8
9
Ä Chapter 8.5 'Main menu' on page 63
Ä Chapter 8.8 'Configuration' on page 89
.
.
111
Control/software
6
10
11
MAN046939 Rev. 6-10.2021
12
