ECOLAB EcoAdd Betriebsanleitung Seite 384

Wearing parts, spare parts and accessories
Pump head 120 l/h [PVDF]
1
2
Fig. 103: Spare part sub-assembly: Pump head 120 l/h
Item Description
A Adhesive label for commissioning / tightening torque (6 Nm)
1 Hexagon socket screw, M 6 x 90, DIN 912, V2A
2 Washer, 17 x 6.4 x 3 DIN 7349 V2A
3 Pump head, 120 l/h, PVDF
Suction/pressure valve, PFC-000 G1¼-G1¼-99
Suction/pressure valve, PEC-000 G1¼-G1¼-99
4
Suction/pressure valve, DFC-000 G1¼-G1¼-99
Suction/pressure valve, DEC-000 G1¼-G1¼-99
5 Diaphragm
6 Intermediate plate
7 Washer, 17 x 6.4 x 3 DIN 7349 V2A
8 Hexagon socket screw, M 6 x 30, DIN 912, V2A, ANTI
9 Adapter plate ECO 120 l/h PPO
a Discharge nozzle, 30/50/120 l/h
10
b Diaphragm breakage sensor
11 O-ring, 10 x 2 70 EPDM 291
12 O-ring, 9 x 1.5 70 EPDM
13 Diaphragm extension, 120 l/h
14 Protective diaphragm
NOTICE!
You must observe the tightening torques on the pump head. (See also
Ä Tightening torque of suction/pressure valves ).
MAN046939 Rev. 6-10.2021
4
A
3
5
4
180
8 9
7
6
10a
Article no.
34900291
413031148
413501304
35200256
249075
249055
252028
252029
35200144
35200252
413501304
413031140
35200253
35200254
252081
417001078
417001062
35200148
35200137
14
13
12
10b
11
EBS no.
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
On request
