ECOLAB EcoAdd Betriebsanleitung Seite 314

Control/software
4
Fig. 58: Configuration: [Batch]
Factory setting: No batch dosing
[Select Batch]:
1.
[Call the main menu]:
2.
[Select Configuration]:
3.
Use the scrollbar to go to the [Batch ] menu item.
4.
[Select Batch].
5.
Select the required batch:
The following batches can be set:
Ä '[Set Batch] - [No batch dosing]' on page 110
n
Ä '[Set Batch] - [Initial batch]' on page 111
n
Ä '[Set Batch] - [ Batch concentration]' on page 112
n
6.
Press the
7.
Press the
8.
Press the
[Set Batch] - [No batch dosing]
4
Fig. 59: Batch - [No batch dosing]
1.
[Call the main menu]:
2.
[Select Configuration]:
3.
Use the scrollbar to go to the [Batch ] menu item.
4.
[Select Batch].
ð Screen switches to the [Batch]
5.
[No batch dosing] selection level.
ð The 'No batch metering' option field is marked.
6.
Press the
7.
Press the
8.
Press the
MAN046939 Rev. 6-10.2021
3 5
Ä Chapter 8.5 'Main menu' on page 63
Ä Chapter 8.8 'Configuration' on page 89
button to return to the [Configuration] menu.
button to return to the [Main menu].
button to return to the [Operating display].
3
Ä Chapter 8.5 'Main menu' on page 63
Ä Chapter 8.8 'Configuration' on page 89
button to return to the [Configuration] menu.
button to return to the [Main menu].
button to return to the [Operating display].
110
