8.3 Display view during ongoing operation (example)
10
11
Fig. 13: Operating display (example)
1 Pump name
Ä Chapter 8.8.1 'Pump name' on page 90
2 Current metering capacity in l/h
Ä Chapter 8.6 'Dosing mode' on page 64
3 Dosing mode (s, m, l, v)
Ä Chapter 8.6 'Dosing mode' on page 64
4 Level display of the metering container
Ä Chapter 10.3 'Changing the container - Empty
signal' on page 149
5 Maintenance display
Ä Chapter 10.4 'Confirming pump service'
on page 153
6
Display of access code
term cancellation of an access code.
7 Variable displays (OGM, calibration, batch,
The pump is operated using the Start button
If the pump is operating, the background of the [Dosing mode] flashes (item 3) and the
Start button
1
15
14
13
12
9
7
8
/ and timer for the short-
(item 11) changes to the Pause button
3
2
4
5
6
external enable, access code, Bluetooth, degas etc.)
Ä 'Symbols during operation (operating mode):'
on page 60
8 Current, day, date and time
Ä Chapter 8.8.2 'Date / time' on page 91
9 Test button for manual metering and bleeding
10 Menu button for calling up the settings
Ä Chapter 8.5 'Main menu' on page 63
11 Start button in standby position ("ON" operating mode)
12 Display of the current percentage metering capacity
13 Current metering capacity
14 Current operating mode
Ä Chapter 8.7 'Operating mode' on page 67
15 Set dosing chemical
Ä Chapter 8.8.10 'Dosing chemical' on page 104
(item 11).
.
