Control/software
[Dosing mode] [V-variable]
Fig. 18: [Dosing mode]: [V-variable]
[Setting dosing mode] [V-variable]
1.
[Call Dosing mode]:
2.
[Select Dosing mode] - [V-variable] (item 1).
3.
[ Press the Next]
ð The screen switches to the setting for the 'Capacity' in l/h.
For the settings, see:
4.
'Use the slider to (item 4) to set the Capacity' to the left of the decimal point (item 3).
5.
Select the field for entering the value after the decimal point (item 5).
6.
'Use the slider to (item 6) set the Capacity' after the decimal point.
7.
Press the Back button
ð The screen switches to the [Dosing mode] overview.
8.
Press the Back button
Pump capacity [l/h]
5
11
30
50
120
MAN046939 Rev. 6-10.2021
2
3
1
Ä 'Select [Dosing mode]' on page 65
button (item 2).
Ä Table on page 66
(item 7) to save your settings.
twice to return to the [Operating display].
4
Setting range [l/h]
0,5 - 5
1,1 - 11
3 - 30
5 - 50
12 - 120
66
7
5
6
