Pump key 'EcoAdd'
The pump key comprises four groups:
Group I: Control unit:
n
Group II: Pump head:
n
Group III: Housing/driver unit:
n
Group IV: Packaging/accessories:
n
Example:
Control unit Pump head
1 2 3 4
EcoAdd E S 01110S
Complete key: EcoAdd ES-01110S-DFC-00S-1S-S0
Pump key: Group I
"Operating unit" [EcoAdd|E|S]
Item 1: 'Pump name/electrical version'
Buttons: On/Off, Menu, Test
Settings: 4 dosing modes, 5 operating modes, dosage rate up to 1:5000
Display: Touch display
Operating modes: Manual, Pulse, Current, Timer, Batch
EcoAdd
Inputs: Enable, Pulse, Power, Batch, Level, Flow rate, Diaphragm rupture
Outputs: Stroke signal, alarm, level
Communication interfaces: USB, CAN bus
Options: "Bluetooth" extension module
Item 2: 'Mains power supply'
E
U
Power cable 2.5 m
N
A
Item 3: 'Control unit version'
S
Standard
T Rotated control unit
B With Bluetooth extension
2 Rotated control unit + Bluetooth expansion (EcoAdd)
Pump key: Group II
"Pump head" [01110S|D|F|C|0|0|S]
Item 4: 'Litre capacity/back-pressure/driver unit'
Key:
00510X
01110S
01110S
03003S
05010M
12003M
Item 5: 'Material: Pump head/valves'
Key:
P
D
D
S
Item 6: 'Material: Seals'
F
E
F
T
K
Item 7: 'Material: Valve balls'
C
C
T
S
Item 8: 'Valve spring'
0
0
Ä 'Pump key: Group I' on page 191
Ä 'Pump key: Group II' on page 191
Ä 'Pump key: Group III' on page 192
Ä 'Pump key: Group IV' on page 192
Housing
5 6 7 8 9 10 11
D F C 0 0 S 1
With Euro plug
With US plug
Without plug (wire end sleeves)
With IEC connector C18 + mains adapter plug C18 / C13 Schuko
Capacity in L: [l/h] Pressure [MPa (bar)]
0,01 - 5 1 (10)
0,01 - 11 1 (10)
0,01 - 30 0,3 (3)
0,01 - 50 1 (10)
0,01 - 120 0,3 (3)
Description:
PP (polypropylene)
PVDF (polyvinylidene difluoride)
Stainless steel (V4A)
FKM (fluorocarbon rubber)
EPDM (ethylene propylene diene monomer rubber)
PTFE coated (polytetrafluoroethylene)
FFPM (Kalrez) (perfluorinated rubber)
Ceramic
PTFE (polytetrafluoroethylene)
Stainless steel V4A
No spring
191
Technical data
Drive Packaging
11 13
S S
Size of driver unit
XS
S
S
M
M
MAN046939 Rev. 6-10.2021
Accessories
14
0
