8.8.7 Dosing release
If the dosing release function activated, the pump runs only when an external enable
contact is closed on terminal 20 and terminal 21 (see
installation' on page 49 ). The selected operating mode does not affect the use of the
dosing release function. A missing release is indicated on the display by a white X on an
orange background
Fig. 46: Configuration: [Dosing release]
Factory setting: Without dosing release
[Set Dosing release]:
1.
[Call the main menu]:
2.
[Select Configuration]:
3.
Use the scrollbar to go to the [ Dosing release] menu item.
4.
[Select Dosing release]
ð The screen switches to the [Dosing release] selection.
5.
If required, select the 'With dosing release' selection box.
ð A tick is shown in the selection field.
6.
Press the
ð The setting is saved, and the screen switches back to the configuration overview.
7.
Press the
8.
Press the
Fig. 47: Display "No dosing release" on the operating screen
(see Fig. 47 )
3
5
4
Ä Chapter 8.5 'Main menu' on page 63
Ä Chapter 8.8 'Configuration' on page 89
button.
button to return to the [Main menu].
button to return to the [Operating display].
Ä Chapter 7.2.2 'Electrical
6
99
