Connection object (class 0x05)

Table 30: Class and Instance Attributes – Connection Object
Object Object Object
class instance attribute
0x05 0x00 0x01
0x05 X 0x01
(see
below)
0x02
0x03
0x04
0x05
0x06
0x07
0x08
0x09
Object description
Revision
of the connection object
State
Connection status
Instance type
Type of connection (either I/O or
messaging)
TransportClass_trigger
Defines the behavior of the
connection
Produced_Connection_ID
(CAN identifier) of the producing
connection
Consumed_Connection_ID
(CAN identifier) of the consuming
connection
Initial_Comm_Characteristics
Defines the message group(s) of this
connection (producing and
consuming)
Produced_Connection_Size
Maximum number of bytes that can
be sent over this connection
Consumed_Connection_Size
Maximum number of bytes that can
be received over this connection
Expected_Packet_Rate
Defines the times for inactivity and
watchdog of this connection
