Discrete Input Point (Class 0X08) - Aventics CMS, B-Design Betriebsanleitung

13.3.6
Table 33:
Object
class
0x08
0x08
Table 34:
Service code
0x0E
Max. instance The value of the "Max. instance" attribute represents the number
of input points. The value is always a multiple of 8 (n × 8 points).
Thus, 3 input modules and an active diagnosis results in:
Max. instance = 0x20 (hex)
Discrete Output Point (Class 0x09)
Table 35:
Object
class
0x09
0x09
AVENTICS | DeviceNet | R499050019–BDL–001–AD

Discrete Input Point (Class 0x08)

Class and Instance Attributes – Discrete Input Point
Object Object
instance attribute
0x00 0x01
0x02
0x01 +i 0x03
Common Services – Discrete Input Point
Service name
Get attribute single
Class and Instance Attributes – Discrete Input Point
Object Object
instance attribute
0x00 0x01
0x02
0x01 + i 0x03
Object description
Revision
of the DeviceNet object
Max. instance
Maximum number of the instances
for this object
Input Point Value
Input data as individual bits i = 0...n
input data bits
Object description
Revision
of the DeviceNet object
Max. instance
Maximum number of the instances
for this object
Output point value
Output data as individual bits
i = 0...n output data bits
137
Appendix
