Aventics CMS, B-Design Betriebsanleitung Seite 109

1)
Examples Subbases used
Example 1 Subbases for double solenoid valves
Example 2 Subbases for double solenoid valves
Example 3 Subbases for double solenoid valves
Example 4 Subbases for single solenoid valves
Example 5 Subbases for double solenoid valves
Combined with
Subbases for single solenoid valves
Example 6 Subbases for double solenoid valves
Combined with
Subbases for single solenoid valves
1)
Other combinations may be selected in accordance with your requirements.
AVENTICS | DeviceNet | R499050019–BDL–001–AD
Examples for the assignment of the S4, S5 and S6 switches and
the supply of assembled valves for 24 valve output stages can
be found in Tab. 15 and Tab. 16 on pages 110, 111 and for 32
valve output stages in Tab. 17 and Tab. 18 on pages 112
and 113 (examples 1 to 3/examples 4 to 6, respectively). The
following example combinations are listed there:
From an electrical connection viewpoint, the subbases for
double solenoid valves must come first and then those for
single solenoid valves. The maximum number of solenoids
for all subbases is 24 (R412004346) or 32 (R412008081).
The assignment of switches and valve supplies changes if
module expansions are used (see operating instructions
R412008961) This also applies to the following examples in
Tab. 15 and Tab. 16.
Commissioning and Operation
Valve equipment
Double solenoid valves
Single solenoid valves
Single and double solenoid valves
Single solenoid valves
Double solenoid valves
Single solenoid valves
Single and double solenoid valves
Single solenoid valves
