Aventics CMS, B-Design Betriebsanleitung Seite 438

438 AVENTICS | DeviceNet | R499050019–BDL–001–AD
Bilaga
Tabell 30: Class and Instance Attributes – Connection Object
Object Object
Class Instance
0x05 X
(se
nedan)
X är definierad enligt följande:
X Anslutningstyp
0x01 Explicit Messaging Connection
0x02 Poll I/O Connection
0x03 Bit Strobe I/O Connection
0x04 COS / Cyclic I/O Connection
0x05 reserverad
Tabell 31: Class Services – Connection Object
Service Code
0x08
Tabell 32: Common Services – Connection Object
Service Code
0x0D
0x0E
0x10
Object
Objektbeskrivning
Attribute
0x0C Watchdog_Timeout_action
definierar hur Inactivity- och
Watchdog-händelser skall behandlas.
0x0D Produced_Connection_Path_Length
Antal byte i attributet
Produced_Connection_Path
0x0E Produced_Connection_Path
specificerar applikationsobjektet(-en),
vars data skickas via denna anslutning
0x0F Consumed_Connection_Path_Length
Antal Byte i Attribut
Consumed_Connection_Path
0x10 Consumed_Connection_Path
specificerar applikationsobjektet(-en),
vars data tas emot via denna
anslutning
Service Name
Create
Service Name
Apply Attribute
Get Attribute Single
Set Attribute Single
