3. Attach the (additional) input (5) or output module (4) to the tie
rods (6).
– Make sure the seals (3) have been correctly inserted and
that the contacts have been properly connected.
4. Retighten the E end plate (2) after the last input module (5)
or output module (4) (2 hexagonal socket-head screws
DIN 912–M4 (1), wrench size 3).
Tightening torque: 2.5 to 3 Nm.
5. Establish the connections (see "Connecting the bus coupler
logic and load supply" on page 100).
6. Adjust the configuration (see "Configuring the bus system"
on page 115).
Disassembly and Exchange
125
