Overview Of The Valve System And Modules - Aventics CMS, B-Design Betriebsanleitung

2
1
7
Fig. 1: Overview: bus coupler sample configuration with I/O modules and mounted VS
1 E end plate
1)
2 Output module
1)
3 Input module
4 Bus coupler, type B-design
1)
A maximum of 6 modules total (input and/or output modules) can be connected in any combination
(e.g. 3 input and 3 output modules).
2)
With separate operating instructions.
AVENTICS | DeviceNet | R499050019–BDL–001–AD
The following system overview outlines the entire valve system
and its components. The VS proper is described in separate
operating instructions.
5.1

Overview of the valve system and modules

The valve system consists of the following parts as illustrated in
Fig. 1 (depending on the order):
5
4
3
6
5 EP end plate for HF03LG or HF04
2)
6 Valve terminal
7 FE connection on the end plate
89
Device description
