13.3 DeviceNet Objects

13.3.1

Identity object (Class 0x01)

Table 23: Class and instance attributes – identity object
Object Object Object
class instance attribute
0x01 0x00 0x01
0x01 0x01 0x01
0x02
0x03
0x04
0x05
0x06
0x07
Table 24: Common services – identity object
Service code
0x05
0x0E
The device is reset with the service class 0x01, instance
0x01, attribute 0x00 for reset service. All communication
connections are interrupted. The settings on the rotary and
DIP switches (MAC ID, baud rate, diagnosis) are read in
again and the assembly is re-initialized.
Object description
Revision
of the Identity Object
Vendor ID
0x11F (hex) AVENTICS GmbH
Product Type
0x07 (hex) general purpose discrete I/O
Product Code
0x12 (hex)
Revision
of the bus coupler RMV04-DN
Status
Summed device status
(bit coding in accordance with the
DeviceNet specifications)
Serial Number
Unique serial number in conjunction
with the Vendor ID
Product Name
"RMV04-DN DeviceNet slave"
Service name
Reset (see below)
Get attribute single
