146 AVENTICS | DeviceNet | R499050019–BDL–001–AD
Appendix

13.5 PLC address assignment

The central PLC addresses are assigned to the decentralized
outputs via a DeviceNet configurator. In Tab. 47 on page 146, you
can find the address assignment for a valve terminal for the
valve positions 1 to 12.
Table 47: Address assignment on a valve terminal from byte 0 to 2
Valve position Solenoid/ LED
1 14
12
2 14
12
3 14
12
4 14
12
5 14
12
6 14
12
7 14
12
8 14
12
9 14
12
10 14
12
11 14
12
12 14
12
Single solenoid valves only use solenoid 14.
Byte Address
0 A0.0
A0.1
A0.2
A0.3
A0.4
A0.5
A0.6
A0.7
1 A1.0
A1.1
A1.2
A1.3
A1.4
A1.5
A1.6
A1.7
2 A2.0
A2.1
A2.2
A2.3
A2.4
A2.5
A2.6
A2.7
