Appendix
Table 30: Class and Instance Attributes – Connection Object
Object Object
class instance
0x05 X
(see
below)
X is defined as follows:
X Connection type
0x01 Explicit messaging connection
0x02 Poll I/O connection
0x03 Bit strobe I/O connection
0x04 COS / cyclic I/O connection
0x05 Reserved
Table 31: Class Services – Connection Object
Service code
0x08
Table 32: Common services – connection object
Service code
0x0D
0x0E
0x10
Object
Object description
attribute
0x0C Watchdog_Timeout_action
Defines how inactivity and watchdog
events should be handled
0x0D Produced_Connection_Path_Length
Number of bytes in the attribute
Produced_Connection_Path
0x0E Produced_Connection_Path
Specifies the application object(s)
whose data is sent over this
connection
0x0F Consumed_Connection_Path_Length
Number of bytes in the attribute
Consumed_Connection_Path
0x10 Consumed_Connection_Path
Specifies the application object(s)
whose data is received over this
connection
Service name
Create
Service name
Apply attribute
Get attribute single
Set attribute single
