DOEPFER SYSTEM A - 100 Bedienungsanleitung Seite 39

doepfer
Modul Breite Strom Strom@5V Beschreibung
A-154
22 60
A-155
50 100
A-156
8 50
A-157
? ?
A-160-1
4 40
A-160-2
4 ?
A-160-5
4 ?
A-161
4 20
A-162
8 40
A-163
8 40
A-164
6 10
A-165
4 20
A-166
8 40
A-167
8 20
System A - 100
Enhanced Sequencer Controller
-
Expansion module for A-155, adds additional running modes and features to A-155
Analog / Trigger Sequencer
-
8 step analog and trigger sequencer
Dual Quantizer
-
two control voltage quantizers with special selection features
Trigger Sequencer
-
8x16 trigger matrix, 8 trigger outputs
Clock Divider
-
frequency divider for clock/gate signals
Clock Divider II
-
3 different sets of dividing factors (power of 2/integer/prime numbers), gate/trigger mode
Clock Multiplier/Ratcheting Controller
-
voltage controlled clock multiplier, 3 sets of multiplication factors
Clock Sequencer
-
clock sequencer expansion for clock divider A-160
Dual Trigger Delay
-
two independent trigger delay devices
Voltage Controlled Divider
-
divides the frequency of an audio signal by an integer factor controlled from a CV
Manual Gate Module
-
three manually generated gate/trigger signals
Dual Trigger Modifier
-
two independent trigger modifiers (inverter + transition edge detector)
Logic Module
-
dual module with logical AND/OR/EXOR combinations + 2 logical inverters
Analog Comparator/Offset-Generator/Subtractor
-
compares the difference of two voltages with fixed value and generates a gate from this
(still under development)
(still under development)
9. Modulübersicht
(still under development)
33
