9. Modul-Übersicht
Die Tabelle dient Ihnen zur Planung und Zusammen-
stellung Ihres Systems A-100 hinsichtlich Platz- und
Modul Breite Strom
[mA]
[TE]
A-101-1
16 30
A-101-2
8 20
A-101-3
30 50
A-101-6
8
A-101-9 8 40
A-102
8 30
A-103
8 30
A-104
20 30
A-105
8 20
A-106-1
14 40
A-106-5
8 30
A-106-6
12 50
System A - 100
Strom@5V Beschreibung
[mA]
Vactrol Steiner Filter
-
Vactrol filter with different inputs (!) for low/band/highpass
Lowpass Gate
-
Combination of lowpass and VCA with vactrol (vactrol = LED/LDR- combination)
12-Stage Modular Vactrol Phase Filter
-
Modular phaser with separate in/outputs for each stage and 2 polarizers
6 stage Opto FET Filter/Phaser
? -
filter module with 6 stages which can be jumpered as lowpass, highpass or allpass
Dual Universal Vactrol Module
-
4 voltaged controlled resistors for modification of other modules
Diode Lowpass
-
voltage controlled 18 dB low pass with diodes as frequency controlling elements
18 dB Lowpass
-
voltage controlled 18 dB low pass (with TB303 type transistor ladder)
Trautonium Formant Filter
-
Quad Low/Band Pass Filter as used in the so-called Trautonium (see A-113)
SSM 24 dB Lowpass
-
voltage controlled 24 dB low pass with the legendary SSM2044 circuit
X-treme filter
-
voltage controlled MS20 filter clone, low/highpass simultaneously, +/- clipping controls
SEM filter
-
voltage controlled 12 dB filter (SEM type), lowpass/notch/highpass with mixer, bandpass
XP filter
-
voltage controlled filter (XP type) with 8 simultaneously available filter types
Strombedarf. Nicht zu allen Modulen sind Anleitungen
verfügbar ! In diesem Fall verweisen wir auf die aus-
führlichen Modulbeschreibungen auf www.doepfer.de.
(still under development)
(module no longer available)
(combined manual A-102/A-103)
(combined manual A-102/A-103)
(combined manual A-105/A-122)
