DOEPFER SYSTEM A - 100 Bedienungsanleitung Seite 37

doepfer
Modul Breite Strom Strom@5V Beschreibung
A-138
8 10/20
a/b/c
A-138d
8 20
A-138e
16 10
A-138m
20 30
A-138u
4 ?
A-138x 8 0
A-139 8 100
A-139-2
6 ?
A-140
8 20
A-141 14 20
A-141-2
14 40
A-142-1
8 40
A-142-4
8 30
A-143-1
28 70
System A - 100
Mixer
, mixer for audio or control voltages
-
c
(a: linear or b: logarithmic controls or c: polarizing mixer)
Manual Crossfader / Effect Insert
-
manually controlled crossfader/effect insert
Triple 3-way Crossfader / Polarizer
-
three manually controlled 3-way crossfaders / polarizers
4 x 4 Matrix Mixer
-
matrix mixer with 4 inputs and 4 outputs
Micro Mixer
-
dual 3-in-1 mixer
Mixer Expander Module
-
expander module A-138xa/xb for A-138a/b, adds 5 inputs to the A-138a/b main module
Headphone Amplifier
-
stereo headphone amplifier with separate level and common loudness control
Headphone Amplifier 2
-
stereo headphone amplifier with separate level and common loudness control
ADSR - Envelope Generator
-
envelope generator with 4 parameters: attack, decay, sustain, release; retrigger function
VC-ADSR Voltage Controlled Envelope Generator
-
voltage controlled envelope generator with 4 voltage controlled parameters
VC-ADSR II - Voltage Controlled Envelope Generator
-
voltage controlled envelope generator with 4 voltage controlled parameters
VC Decay
-
voltage controlled envelope generator with one voltage controlled decay
Quad Decay
-
four simple manually controlled envelope generators with decay as the only parameter
Complex Envelope Generator / Quad AD
-
Four daisy chained AD type envelope generators with polarizing mixer
(still under development)
(module no longer available)
(module no longer available)
(still under development)
9. Modulübersicht
(no longer available)
31
